High-Precision Industrial Plant Scan

Structural Integrity & Clearance Assessment

A full-scale 3D laser scanning project conducted within an operational industrial plant to generate a high-precision point cloud dataset for retrofit engineering and renovation planning. The capture process ensured millimeter-level accuracy while maintaining uninterrupted facility operations.
High-Precision Industrial Plant Scan

Project Overview

This project involved high-resolution terrestrial laser scanning of an active industrial facility to generate a comprehensive point cloud dataset.
  • Full structural capture of steel frames and piping systems
  • MEP systems documentation
  • Millimeter-level accuracy validation
  • Scan registration and noise cleaning
The final dataset was delivered in RCP and E57 formats for engineering integration.
Project imageProject imageProject imageProject imageProject imageProject image
High-Precision Industrial Plant Scan

Technical Scope & Deliverables

Our team deployed multi-station LiDAR scanners to ensure zero blind spots across the plant.
  1. Site preparation & control point setup
  2. 360° laser scanning execution
  3. Cloud-to-cloud registration
  4. Quality assurance & density optimization
The point cloud was optimized for direct import into BIM software for retrofit modeling.
